Yoko Cctv Dome Cameras

  Yoko RYK3211 Dome Camera   Specifications

  Yoko RYK3211 CCTV Dome Camera,Chennai India.
1/3" CL Mini Dome Camera

• Sony Super HAD CCD sensor
• Built-in Board Lens
• Weatherproofing criterion IP 66


Model Name RYK-2311
Image Device 1/3" Color Sony Super HAD
Picture Elements NTSC:510x492, PAL:500x582
Resolution 420 TVL
Min. Illumination 0.2 Lux / F 2.0
S/N Ratio More than 48dB
Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000
Gamma 0.45
Lens Furnished Board Lens 3.6mm / F2.0 (option:2.5/4.3/6/8/12/16mm)
White Balance Auto
Gain Control Auto
Sync. System Internal
Video Output 1 Vp-p / 75 Ohms
Audio Output 2 Vp-p / 50 Ohms (option)
Power Supply DC12V±10%
Power Consumption 117mA max.
Operating Temp. -10°C ~ 50°C

Yoko RYK3211 CCTV Dome Camera,Chennai India.

  Yoko RYK2311/4 Dome Camera   Specifications

  Yoko RYK2311/4 CCTV Dome Camera,Chennai India.
1/3" Sony Super HAD CCD Sensor
Built in Board Lens
3-Axis Movement for free Lens Rotation
Wall or Ceiling Mount
DC Voltage


Model Name

RYK-2311/4

Image Device 1/3" Color Sony Super HAD
Picture Elements NTSC:510x492, PAL:500x582
Resolution 420 TVL
Min. Illumination 0.2 Lux / F 2.0
S/N Ratio More than 48dB
Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000
Gamma 0.45
Lens Furnished Board Lens 3.6mm / F2.0
White Balance Auto
Gain Control Auto
Sync. System Internal
Video Output 1 Vp-p / 75 Ohms
Power Supply DC12V±10%
Power Consumption 117mA max.
Operating Temp. -10°C ~ 50°C
